GENERAL INFORMATION
Operating Temperature | -20 °C / +50°C -40 °C / +70°C (optional) -5 °C / +50 °C (optional) (with emergency kit) -5 °C / +70 °C (optional) (with emergency kit) |
Storage Temperature | -40°C / +80°C |
Main Reference Company Standards | EN 60598-1, EN 60598-2-1, EN 62471, EN 60068-2-11, EN60068-2-52, ISO9227, ASTMB117, ASTMD3359-78, ISO 4628-2, ISO 4628-4, EN 60529, EN 62262, ANSIC136.10-2017, ANSI C136.2-2018, EN 62031, IEC 62384, ASTM D3359, EN ISO 2409, IES LM 80-15, IES LM 82-12, IES LM 84,14, IES LM 85-14, IES TM 21-11, CE, ISO9001, ISO14001, ISO18001, ISO5001, ISO45001, ISO39001, EAC, TURKAK |
ELECTRICAL INFORMATION
Electrical Class | Class I, Class II (optional) |
Nominal Voltage | 220-240V 50 / 60 Hz EU 110-277V 50 / 60 Hz (optional) NORTH AMERICA |
Led Current | 250 mA, 300 mA, 350 mA, 500 mA, 600 mA |
LED Lamp Power | 20W, 30W, 36W, 42W, 55W |
Power Factor | ≥0.9 (at full load) |
Driver | Constant current, thermal protected, voltage regulated, harmonic filter protection |
Surge protection options (kV) | 1 Kv (standard) 10 kV (optional) with LED signal and thermo fuse to disconnect load at the end of life |
Emergency Kit (optional) | 1 hour battery 3 hours batteries |
Control system | on-off (standard), Bluetooth, DALI, 1-10V DIM, stand alone automation |
Sensor | PIR (optional), Photocell (optional) |
Mains connection | For cable max section 2,5 mm2 Outgoing cable H05RN-F 2/3/5 x 1,5 mm2 Length on request.(optional) |
Electromagnetic compatibility (EMC) | IEC 61000, EN 55015, IEC 61000-3-2, IEC 61000-4-5, IEC 61547, IEC 61000-3-3, IEC 61000-4-2, IEC 61000-2-2, IEC 61000-4-11, IEC 61643-11 |
HOUSING AND MATERIALS
Housing | Aluminium extrusion |
Gasket | Silicon or polyurethane without junction points. |
Refractor | Polycarbonate (PC) |
Reflector | Powder painted sheet steel |
Cable Gland | IP65, Plastic PG7, IP66 (optional), IP67 (optional) |
Tightness Level | IP65 |
Impact Housing Resistance | IK08 (5 J) |
Impact Glass Resistance | IK08 (5 J) |
Vibration Test | Compliant with modified IEC 68-2-6 (0.5G), ANSI C136.31 (3G-5G) |
OPTICAL INFORMATION
Led colour temperature | 3000K (warm white) 4000K (neutral white) (standard) 5000K (cool white) 6500K (cool white) |
Colour rendering ındex (CRI) | CRI ≥80 CRI ≥90 (optional) |
Upward light output ratio | 0% |
Photobiological safety class | IEC 62471, EN 62778 EXEMPT GROUP |
Testing standard | LM 79-19 , EN 13032-1 (all measurements in ISO17025 accredited laboratory) |
Lifetime of the LED's | Tq= 25 ° , 700 Ma ≥ 100.000h -L70 Tq= 55 ° , 700 Ma ≥ 100.000h -L70 |
Main Application
